Home » Producten » GSM/GPRS/3G/4G/5G/PSTN/LoRa » Industrial 4G LTE » 4G LTE Routers » MRD-405 Series

MRD-405 Series

Industrial mobile broadband /4G router

Login to see the price of this product.
Login

  Datasheet

Artikelnummer: MRD-405 Series Categorie: 4G LTE Routers
  • Beschrijving
  • Extra informatie
  • Modellen
  • Contact

Beschrijving

Remote access removes boundaries, eliminates the need for time consuming site visits and provides a network infrastructure suitable for today’s ”always on” society. The MRD-405 uses the Internet to cost effectively inter-connect systems, allowing HMI, PLCs, sensors etc to communicate with each other, a pre-requisite for any Industrial Internet (IIoT/ IoT) solution.

A compact case design with a power input range between 12 to 24 VDC make the unit well suited for industrial applications. Easy integration with other devices is achieved using the built-in two port Ethernet switch.

The stability of mobile connections can be affected by a variety of parameters and in order to ensure constant connectivity the MRD-series features the customer praised connection manager. The unit will monitor the cellular connection and, without human-interaction, solve most network related issues, preventing unnecessary power-cycle site visits.

The MRD-405 offers network protection from malicious eavesdroppers via encrypted communication tunnels (VPN), and features a simple, yet powerful, packet inspection firewall.

Requirements and needs vary between different types of M2M/IIoT applications. Sometimes all that is needed is a reliable gateway to the internet whereas other applications might have simpler devices that need to be securely connected to each other, or a server, via a VPN. Regardless of which type of remote access application you might have the MRD-405 can fulfill your communication needs. The unit works very well with any type of SIM card, such as static IP SIM, M2M SIM, or an off-the-shelf SIM.

Configuring the unit is very easy with the built-in web-interface, no need for special AT-commands or similar. The device can also provide both management and monitoring via SMS, for example an SMS could be sent to start a VPN.



Features and Benefits

Industrial remote access using the Internet

  • Economic and environmental benefits
  • Access SCADA systems, HMI and PLCs remotely
  • Cellular 2G / 3G / 4G connections

Designed for industrial applications

  • Compact casing for easy integration
  • Power input range, 12 to 24 VDC
  • Built-in two port Ethernet switch

Secure resilient Internet access

  • The connection manager monitors and ensures constant connectivity
  • Easy to use firewall prevents unauthorized access
  • Encrypted and secure data transmission with VPN-tunnels

A wide variety of communication solutions

  • Can act as a gateway to the internet
  • Works very well with M2M type SIM cards
  • Management via easy to use web-interface or SMS



Extra informatie

Merk

Westermo

Netwerk

4G LTE

SIM slot

1

Medium

RJ45

Interfaces

100Mbps

Modellen

ModelProductomschrijving
Industrial mobile broadband /4G router
